产品详情
产品应用
充电器、智能电表、BMS、工业设备、医疗设备
MOS继电器目录
| Pin Configuration | Package Type | Part Number | IL (mA) Max. | VL (V)Max. | Rd(on) (Ω) Max. | ILpeak (A) Max. | IF(0n (mA) Max. | IF(0ff) (mA)Max. | Ton (ms) Max. | Toff (ms) Max. |
 | DIP4 | TAQY212 | 550 | 60 | 2.5 | 1.2 | 5 | 0.4 | 3 | 0.5 |
| TAQY214 | 120 | 400 | 30 | 0.3 | ||||||
| TAQY216 | 50 | 600 | 70 | 0.15 | ||||||
| TAQY217 | 180 | 250 | 15 | 0.5 | ||||||
| SOP4 | TAQY212S | 550 | 60 | 2.5 | 1.2 | 5 | 0.4 | 3 | 0.5 |
| TAQY214S | 120 | 400 | 30 | 0.3 | ||||||
| TAQY216S | 50 | 600 | 70 | 0.15 | ||||||
| TAQY217S | 180 | 250 | 15 | 0.5 | ||||||
 | DIP6 | TAQV212 | 550 | 60 | 3 | 1.2 | 5 | 0.4 | 3 | 0.5 |
| TAQV214 | 120 | 400 | 30 | 0.3 | ||||||
| TAQV216 | 50 | 600 | 70 | 0.15 | ||||||
| TAQV217 | 180 | 250 | 15 | 0.5 | ||||||
 | DIP8 | TAQW212 | 550 | 60 | 2.5 | 1.2 | 5 | 0.4 | 3 | 0.5 |
| TAQW214 | 120 | 400 | 30 | 0.3 | ||||||
 | SOP4 | TAQY414S | 120 | 400 | 30 | 0.3 | 5 | 0.4 | 3 | 1 |
